China Kingflex foam ruber tube pipe insulation Factory, Pricelist

Kingflex foam ruber tube pipe insulation, Rubber as the main raw material ,no fiber ,non-formaldehyde, non-CFC and other ozone-depleting refrigerant ,can be directly exposed to the air, nor harm for human health. Standard product is black, It also efficiently reduces heat transfer for hot-water plumbing and liquid-heating and dual-temperature piping. It is ideal for applications in ductwork, dual temperature and low pressure steam line,process piping Air-conditioner, including hot gas piping. Nominal wall thicknesses of 1/4”, 3/8″, 1/2″, 3/4″,1″, 1-1/4”, 1-1/2″ and 2” (6, 9, 13, 19, 25 , 32, 40 and 50mm). Standard Length with 6ft (1.83m) or 6.2ft(2m).

Product Description

Rubber foam insulation tube is a uniquely formed closed cell flexible elastomeric insulation, used to insulate heating, ventilating, air-conditioning, refrigerating (HVAC/R). The Insulation tube is also CFC/HCFC free, non-porous, fiber free, dust free and resistant to mold growth. The recommended temperature range for insulation is -50℃ to +110℃.

Technical Data Sheet
Technical Data
Property Unit Value Test Method
Temperature range °C (-50 - 110) GB/T 17794-1999
Density range Kg/m³ 45-65Kg/m³ ASTM D1667
Water vapor permeability Kg/(m.s.pa) ≤0.91×10 ﹣¹³ DIN 52 615 / BS 4370 Part 2 1973
μ - ≥10000 -
Thermal Conductivity W/(m.k) ≤0.030 (-20°C) ASTM C 518
≤0.032 (0°C)
≤0.036 (40°C)
Fire Rating - Class 0 & Class 1 BS 476 Part 6 part 7
Flame Spread and Smoke Developed Index - 25/50 ASTM E 84
Oxygen Index - ≥36 GB/T 2406, ISO4589
Water Absorption, % by Volume % 20% ASTM C 209
Dimension Stability - ≤5 ASTM C534
Fungi resistance - Good ASTM 21
Ozone resistance Good GB/T 7762-1987
Resistance to U.V. and weather Good ASTM G23
Key Features
✓ Closed-cell Structure
✓ Low Heating Conductivity
✓ Low Water Absorption Rate
✓ Good Fireproof and Soundproof
✓ Good Aging Resistance
✓ Simple and Easy Installation
Product Gallery
Frequently Asked Questions
Q1 What applications are these rubber foam insulation tubes designed for?
They are designed to insulate heating, ventilating, air-conditioning, and refrigerating (HVAC/R) systems to prevent heat loss and condensation.
Q2 What is the recommended operating temperature range?
The recommended operating temperature range for this elastomeric insulation is from -50℃ to +110℃.
Q3 Are these insulation tubes environmentally safe and mold resistant?
Yes, the insulation tubes are CFC/HCFC free, non-porous, fiber free, dust free, and provide excellent resistance to mold growth.
Q4 What are the fire safety ratings of this material?
The material achieves a Class 0 & Class 1 fire rating according to the BS 476 Part 6 & Part 7 test standards.
Q5 How does the material perform against weather and UV exposure?
It features good resistance to U.V. radiation, ozone, and outdoor weathering conditions, ensuring a long-lasting service life.
